MGJ-H560LS / H560LS-S Mobile Spray Fan Series

Stainless Steel Body · Extra-Large Water Tank · Automatic Oscillation · Industrial-Grade Humidification & Cooling

The MGJ-H560LS series mobile spray fans represent a premium solution for large-scale humidification and cooling in controlled agricultural and industrial environments. Constructed with a corrosion-resistant stainless steel body and powered by advanced centrifugal atomization technology, the system disperses ultra-fine water mist to effectively reduce ambient temperature by 4–8°C while maintaining stable humidity.

Engineered for durability, efficiency, and versatility, the H560LS series integrates an extra-large 150–170L water tank for long-duration operation, paired with automatic oscillation to ensure wide-angle mist distribution and uniform coverage across cultivation zones, warehouses, and livestock areas.

Key Advantages

• Stainless Steel Body
  Heavy-duty 201 stainless steel (with optional 304 upgrade) provides long service life, corrosion resistance, and robust structural stability for demanding environments.

• Extra-Large Water Tank (150–170L)
  Enables extended humidification cycles, minimizing refilling frequency and supporting uninterrupted operation.

• Powerful Airflow & Wide Mist Coverage
  High-performance motor delivers strong airflow, ensuring rapid cooling and efficient mist dispersion across up to 350 m² of coverage.

• Automatic Oscillation
  Built-in oscillation system provides ≤120° wide-angle airflow, eliminating stagnant pockets and ensuring consistent microclimate regulation.

• Mobility & Flexibility
  Equipped with heavy-duty caster wheels, the system is easy to move and position, ideal for flexible deployment across different zones.

• Safety & Reliability
  Integrated leakage protection switch enhances operator safety and ensures dependable performance in continuous-use environments.

Technical Specifications

Applications

The MGJ-H560LS series is ideally suited for:

• Agricultural Greenhouses – temperature and humidity regulation for vegetables, fruits, and specialty crops.

• Horticulture Facilities – ensuring optimal growth conditions in vertical farming and controlled-environment agriculture (CEA).

• Livestock Farms – reducing heat stress and maintaining animal welfare in poultry, swine, and cattle facilities.

• Warehousing & Logistics – improving air quality, dust suppression, and humidity stabilization for sensitive storage.

• Industrial Workshops – textile, food processing, and electronics industries requiring static control, cooling, and humidification.

Additional Information

• Material: Standard 201 stainless steel, optional upgrade to 304 stainless steel.

• Safety: Built-in leakage protection switch for safe operation.

• Warranty:1-year full machine warranty, with extended maintenance options available.

✨ The MGJ-H560LS series mobile spray fans deliver professional-grade cooling and humidification with a stainless steel design, extended autonomy, and wide-area coverage—making them an indispensable solution for modern agriculture and industrial environments.

MGJ-H560LS / H560LS-S 不锈钢移动喷雾风机
（工业级加湿 & 降温｜大水箱 · 自动摇摆 · 强劲风量）

✅ 不锈钢机身：201 不锈钢（可升级 304），耐腐蚀，使用寿命长
✅ 超大水箱：150–170L，大幅减少加水频率，支持长时间运行
✅ 高效降温加湿：雾化量 0–20 L/h，可降温 4–8 ℃，覆盖面积 ≤350㎡
✅ 自动摇摆送风：≤120°广角气流，避免死角，环境更均匀
✅ 灵活移动：重型脚轮，轻松部署到温室、养殖场或车间
✅ 安全可靠：内置漏电保护开关，保障连续运行

应用场景
温室大棚 & 垂直农场
园艺与设施农业
畜牧养殖（禽舍、猪舍、牛舍）
仓储物流（纸品、木材、药材等）
工业车间（纺织、食品加工、电子厂）

⚙️ 参数一览

• 水箱容量：150–170L

• 覆盖面积：≤350㎡

• 摇摆角度：≤120°

• 功率：340W–800W（4极/6极可选）

• 尺寸：650×610×1650 mm

• 重量：43–44 kg

为什么选 MGJ-H560LS 系列？
不锈钢结构 + 超大水箱 + 自动摇摆 = 专业级环境控制方案
农业 & 工业多场景适用 · 全球发货 · 支持 OEM/ODM
